Avid
S-SERIES
Control Surfaces
AVID // S1
Avid's high-end consoles offer unparalleled speed, rich visual feedback and software integration. The sleek S1 is an easy fit for any space or budget with its deep hands on control of favorite audio/video programs including Pro Tools, Media Composer, Logic Pro X, Cubase, Nuendo, and Premiere Pro among many others; together providing great ergonomic efficiency while mixing intuitively leading to better sounding mixes faster than ever.
Specifications
Faders: Eight motorized, touch-sensitive, 100 mm long-throw faders
Knobs: Eight push-top, touch-sensitive rotary encoders
Additional Controls: Assorted hardware buttons/keys for various functions and mode selections, including Mute, Solo, Record-enable, Bank, Nudge, and more
Software Interface: Supports the free Avid Control app running on iPad or Android tablet (tablet not included)
Displays: Eight high-resolution OLED displays, plus multiple status LEDs and multicolor track buttons; channel metering, monitoring, processing, track status, automation modes, and other views provided by Avid Control on your tablet
Scalability: Connect up to four S1 controllers together, plus Avid Dock, to create an extended, fully integrated surface
Height: (front, rear) 1.2 inches, 3.8 inches (29 mm, 97 mm)
Width: 12.3 inches (312 mm)
Depth: 14.9 inches (377 mm)
AVID // S3
.png)
The AVID S3 Control Surface is the key to unlocking your creativity. With 16 touch sensitive, motorized faders you can mix like a pro and master tracks like never before. You'll be able to navigate through projects using navigation strips on top of transport controls for perfecting any soundscape--whether it’s music or video game soundtrack making magic happen in real time with just one tap away.
AVID // S4
The Avid S4 is a compact 24-channel mixing surface that delivers industry standard, award winning workflows in a more streamlined and intelligent layout. Whether you're creating music or designing sound for immersive audio projects, it has everything needed to get the job done perfectly at an accessible price point.
AVID // S6
Experience the most intuitive and immersive mixing workflows for modern sound engineers. The revolutionary Avid S6 modular control surface leverages all of our industry-leading products, providing superior ergonomics that is unmatched in this space with intelligent studio access controls along side fully integrated Dolby Atmos support right out of box.
Design the perfect mixing surface for your workflow. S6 is fully modular, enabling you to build your own system with an accompaniment of Fader, Knob, Process, and Display Modules. Add optional modules for surround and post mixing. Personalize it further with a variety of accessories, from keyboard and script trays to speaker mounts. And because it can be scaled horizontally and vertically, you can configure the surface with the modules you need now to fit your budget, with room to expand in the future as your needs grow.
Stay on top of your mix with one or more Display Modules, which provide extensive and unique visual feedback. Not only can you view multiple channel meters, track names, routing, groups, and other information, but also insightful data that will elevate your mixing experience. View high-resolution scrolling Pro Tools waveforms, which you can edit right from the surface. Display track automation data, gain reduction metering, EQ curves, and more. And with the latest EUCON software, you can now turn the display into a Master Meter Module, so you can keep your Master and Bus meters visible at all times.
